Trie (Prefix Tree)

A Trie (pronounced "try", from retrieval) is a tree-based data structure designed for storing and searching strings with shared prefixes. Unlike a HashMap, a Trie lets you search by prefix in O(m) time where m is the length of the word — making it the backbone of search autocomplete, spell checkers, and IP routing.

Video Explanation

Data Structures: Tries - YouTube thumbnail

🧠 Why Trie? — Comparison with Other Structures

Store words: ["apple", "app", "apt", "bat", "ball"]
Then answer: "Give all words starting with 'ap'"

❌ Array/List:
  Scan every word → O(n × m) per query → slow for large dictionaries

❌ HashMap:
  O(1) exact lookup but NO prefix search support
  "app" → exists, but "give all words starting with ap" requires scanning all keys

✅ Trie:
  Insert: O(m) per word
  Prefix search: O(m) to reach prefix node, then collect all words below → Fast!

🌳 Trie Structure — Visual Diagram

Words inserted: ["app", "apple", "apt", "bat", "ball"]

                root
               /    \
              a      b
              |      |
              p      a
             / \    / \
            p   t  t   l
            |   |  |   |
           [✓] [✓][✓]  l
            |           |
            l           [✓]
            |
            e
            |
           [✓]

[✓] = isEndOfWord is true

Paths from root:
root→a→p→p        = "app"   ✓
root→a→p→p→l→e    = "apple" ✓
root→a→p→t        = "apt"   ✓
root→b→a→t        = "bat"   ✓
root→b→a→l→l      = "ball"  ✓

🔩 Node Structure

Each Trie node contains:
1. children[26]  → array of 26 pointers (one per lowercase letter a-z)
                   children[0] = pointer to 'a' child
                   children[1] = pointer to 'b' child
                   ...
                   children[25] = pointer to 'z' child
2. isEndOfWord   → boolean flag: true if a valid word ends at this node

Initially all children = null, isEndOfWord = false

➕ Operation 1: Insert

Visual Dry-Run — Insert "app"

Start at root. Word = "app"

Character 'a':
  root.children[0] == null? → YES → create new node
  Move to children[0]

Character 'p':
  node.children[15] == null? → YES → create new node
  Move to children[15]

Character 'p':
  node.children[15] == null? → YES → create new node
  Move to children[15]

End of word → set isEndOfWord = true ✓

root → [a] → [p] → [p*]     (* = end of word)

Visual Dry-Run — Insert "apple" after "app"

Word = "apple"

'a' → node exists (root.children[0]) → just move, no new node
'p' → node exists → just move
'p' → node exists → just move  (this was end of "app", stays end)
'l' → null → create new node, move
'e' → null → create new node, move
End → isEndOfWord = true ✓

root → [a] → [p] → [p*] → [l] → [e*]

Code

Python
Java
C++

class TrieNode:
    def __init__(self):
        self.children = {}        # char → TrieNode
        self.is_end_of_word = False

class Trie:
    def __init__(self):
        self.root = TrieNode()

    def insert(self, word: str) -> None:
        node = self.root
        for char in word:
            if char not in node.children:
                node.children[char] = TrieNode()   # create node if missing
            node = node.children[char]              # move to next node
        node.is_end_of_word = True                  # mark end of word

# Example
trie = Trie()
trie.insert("app")
trie.insert("apple")
trie.insert("apt")

import java.util.HashMap;

class TrieNode {
    HashMap<Character, TrieNode> children;
    boolean isEndOfWord;

    public TrieNode() {
        children = new HashMap<>();
        isEndOfWord = false;
    }
}

public class Trie {
    protected TrieNode root;

    public Trie() {
        root = new TrieNode();
    }

    public void insert(String word) {
        TrieNode node = root;
        for (char c : word.toCharArray()) {
            if (!node.children.containsKey(c)) {
                node.children.put(c, new TrieNode());  // create node if missing
            }
            node = node.children.get(c);               // move to next node
        }
        node.isEndOfWord = true;                       // mark end of word
    }
}

#include <vector>
#include <string>
#include <iostream>
using namespace std;

struct TrieNode {
    vector<TrieNode*> children;
    bool isEndOfWord;

    TrieNode() : children(26, nullptr), isEndOfWord(false) {}
    ~TrieNode() {
        for (auto child : children) {
            delete child;
        }
    }
};

class Trie {
public:
    TrieNode* root;

    Trie() {
        root = new TrieNode();
    }

    ~Trie() {
        delete root;
    }

    void insert(const string& word) {
        TrieNode* node = root;
        for (char c : word) {
            int idx = c - 'a';
            if (!node->children[idx]) {
                node->children[idx] = new TrieNode();  // create node if missing
            }
            node = node->children[idx];                // move to next node
        }
        node->isEndOfWord = true;                      // mark end of word
    }
};

Time Complexity: O(m) where m = length of word Space Complexity: O(m) per word inserted

🔍 Operation 2: Search (Exact Word)

Visual Dry-Run

Trie contains: ["app", "apple", "apt"]

root → [a] → [p] → [p*] → [l] → [e*]
                  ↘ [t*]

Search "app":
'a' → exists → move
'p' → exists → move
'p' → exists → move
End → isEndOfWord = TRUE ✅ → "app" EXISTS

Search "ap":
'a' → exists → move
'p' → exists → move
End → isEndOfWord = FALSE ❌ → "ap" is NOT a word
(node exists as prefix but not marked as complete word)

Code

Python
Java
C++

    def search(self, word: str) -> bool:
        node = self.root
        for char in word:
            if char not in node.children:
                return False        # path doesn't exist
            node = node.children[char]
        return node.is_end_of_word  # true only if complete word

    public boolean search(String word) {
        TrieNode node = root;
        for (char c : word.toCharArray()) {
            if (!node.children.containsKey(c)) {
                return false;           // path doesn't exist
            }
            node = node.children.get(c);
        }
        return node.isEndOfWord;        // true only if complete word
    }

    bool search(const string& word) {
        TrieNode* node = root;
        for (char c : word) {
            int idx = c - 'a';
            if (!node->children[idx]) {
                return false;           // path doesn't exist
            }
            node = node->children[idx];
        }
        return node->isEndOfWord;       // true only if complete word
    }

Time Complexity: O(m) | Space Complexity: O(1)

🔎 Operation 3: StartsWith (Prefix Search)

Visual Dry-Run

startsWith("ap"):
'a' → exists → move
'p' → exists → move
Reached end of prefix → node exists → TRUE ✅

startsWith("bx"):
'b' → exists → move
'x' → does NOT exist → FALSE ❌

Key difference:
search("ap")     → FALSE (not a complete word)
startsWith("ap") → TRUE  (it IS a valid prefix)

Code

Python
Java
C++

    def starts_with(self, prefix: str) -> bool:
        node = self.root
        for char in prefix:
            if char not in node.children:
                return False        # prefix path doesn't exist
            node = node.children[char]
        return True                 # prefix exists

    public boolean startsWith(String prefix) {
        TrieNode node = root;
        for (char c : prefix.toCharArray()) {
            if (!node.children.containsKey(c)) {
                return false;           // prefix path doesn't exist
            }
            node = node.children.get(c);
        }
        return true;                    // prefix exists
    }

    bool startsWith(const string& prefix) {
        TrieNode* node = root;
        for (char c : prefix) {
            int idx = c - 'a';
            if (!node->children[idx]) {
                return false;           // prefix path doesn't exist
            }
            node = node->children[idx];
        }
        return true;                    // prefix exists
    }

Time Complexity: O(m) | Space Complexity: O(1)

🗑️ Operation 4: Delete

Visual Dry-Run

Delete "app" from Trie containing ["app", "apple", "apt"]

Before:
root → [a] → [p] → [p*] → [l] → [e*]
                  ↘ [t*]

Strategy: Only unmark isEndOfWord at the last node.
Do NOT delete the node — "apple" still needs this path!

After deleting "app":
root → [a] → [p] → [p] → [l] → [e*]   ← 'p' no longer end of word
                  ↘ [t*]

search("app")   → FALSE ✅ (deleted)
search("apple") → TRUE  ✅ (intact)

Code

Python
Java
C++

    def delete(self, word: str) -> bool:
        if not self.search(word):
            return False

        def _delete(node, word, depth):
            if depth == len(word):
                node.is_end_of_word = False
                return len(node.children) == 0

            char = word[depth]
            if _delete(node.children[char], word, depth + 1):
                del node.children[char]
                return len(node.children) == 0 and not node.is_end_of_word
            return False

        _delete(self.root, word, 0)
        return True

    public boolean delete(String word) {
        if (!search(word)) return false;
        deleteHelper(root, word, 0);
        return true;
    }

    private boolean deleteHelper(TrieNode node, String word, int depth) {
        if (depth == word.length()) {
            node.isEndOfWord = false;
            return node.children.isEmpty();
        }

        char c = word.charAt(depth);
        boolean shouldDelete = deleteHelper(node.children.get(c), word, depth + 1);

        if (shouldDelete) {
            node.children.remove(c);
            return node.children.isEmpty() && !node.isEndOfWord;
        }

        return false;
    }

    bool deleteWord(const string& word) {
        if (!search(word)) return false;
        deleteWordHelper(root, word, 0);
        return true;
    }

private:
    bool deleteWordHelper(TrieNode* node, const string& word, int depth) {
        if (depth == (int)word.size()) {
            node->isEndOfWord = false;
            for (auto child : node->children)
                if (child) return false;
            return true;
        }

        int idx = word[depth] - 'a';
        bool shouldDelete = deleteWordHelper(node->children[idx], word, depth + 1);

        if (shouldDelete) {
            delete node->children[idx];
            node->children[idx] = nullptr;
            if (!node->isEndOfWord) {
                for (auto child : node->children)
                    if (child) return false;
                return true;
            }
        }

        return false;
    }

Time Complexity: O(m) | Space Complexity: O(m) recursion stack

✨ Bonus: AutoComplete Feature

Visual Dry-Run

Trie: ["app", "apple", "apt", "bat", "ball"]
AutoComplete("ap"):

Step 1: Navigate to node for prefix "ap"
  root → 'a' → 'p' → [at this node]

Step 2: DFS from this node collecting all complete words
  → 'p'* → found "app"
       → 'l' → 'e'* → found "apple"
  → 't'* → found "apt"

Result: ["app", "apple", "apt"] ✅

Code

Python
Java
C++

class TrieWithAutoComplete(Trie):
    def autocomplete(self, prefix: str) -> list:
        node = self.root

        # Navigate to prefix node
        for char in prefix:
            if char not in node.children:
                return []
            node = node.children[char]

        # DFS to collect all words
        results = []
        self._dfs(node, prefix, results)
        return results

    def _dfs(self, node, current_word, results):
        if node.is_end_of_word:
            results.append(current_word)
        for char, child_node in node.children.items():
            self._dfs(child_node, current_word + char, results)

# Example
trie = TrieWithAutoComplete()
for word in ["app", "apple", "apt", "bat", "ball"]:
    trie.insert(word)

print(trie.autocomplete("ap"))   # ['app', 'apple', 'apt']
print(trie.autocomplete("ba"))   # ['bat', 'ball']
print(trie.autocomplete("xyz"))  # []

import java.util.ArrayList;
import java.util.List;

public class TrieWithAutoComplete extends Trie {

    public List<String> autocomplete(String prefix) {
        TrieNode node = root;
        List<String> results = new ArrayList<>();

        // Navigate to prefix node
        for (char c : prefix.toCharArray()) {
            if (!node.children.containsKey(c)) return results;
            node = node.children.get(c);
        }

        // DFS to collect all words
        dfs(node, new StringBuilder(prefix), results);
        return results;
    }

    private void dfs(TrieNode node, StringBuilder current, List<String> results) {
        if (node.isEndOfWord) {
            results.add(current.toString());
        }
        for (char c : node.children.keySet()) {
            current.append(c);
            dfs(node.children.get(c), current, results);
            current.deleteCharAt(current.length() - 1);  // backtrack
        }
    }
}

class TrieWithAutoComplete : public Trie {
public:
    vector<string> autocomplete(const string& prefix) {
        TrieNode* node = root;
        vector<string> results;

        // Navigate to prefix node
        for (char c : prefix) {
            int idx = c - 'a';
            if (!node->children[idx]) return results;
            node = node->children[idx];
        }

        // DFS to collect all words
        string current = prefix;
        dfs(node, current, results);
        return results;
    }

private:
    void dfs(TrieNode* node, string& current, vector<string>& results) {
        if (node->isEndOfWord) results.push_back(current);
        for (int i = 0; i < 26; i++) {
            if (node->children[i]) {
                current.push_back('a' + i);
                dfs(node->children[i], current, results);
                current.pop_back();     // backtrack
            }
        }
    }
};

⚡ Brute Force vs Trie

Dictionary: 100,000 words, average length 8
Query: "Find all words starting with 'pre'"

❌ BRUTE FORCE — O(n × m):
  Check every word: 100,000 × 8 = 800,000 operations per query

✅ TRIE — O(m + k):
  Navigate prefix "pre": 3 steps
  Collect k=500 matching words: 503 operations total

Speedup: ~1,600x faster ✅

📊 Complexity Summary

Operation	Time	Space
Insert	O(m)	O(m)
Search	O(m)	O(1)
StartsWith	O(m)	O(1)
Delete	O(m)	O(m) stack
AutoComplete	O(m + k)	O(k)

m = length of word/prefix | k = number of results returned

❌ Common Mistakes

Confusing search() and startsWith() — search("app") checks for a complete word. startsWith("app") checks for any word with that prefix. They return different results!
Deleting shared prefix nodes — Never delete a node if other words share its path. Always check children before removing.
Case sensitivity — Tries are case-sensitive. Always normalize input to lowercase before inserting or searching.
Array vs HashMap for children — Array children[26] is O(1) access but wastes memory. HashMap uses less memory but has overhead. Choose based on your character set size.
Forgetting isEndOfWord — Inserting "apple" without marking isEndOfWord=true causes search("apple") to return false even though the path exists.

🏋️ Practice Problems

#	Problem	Concept	Difficulty
1	Implement Trie (Prefix Tree)	Insert, Search, StartsWith	🟡 Medium
2	Longest Common Prefix	Trie traversal	🟢 Easy
3	Design Add and Search Words	Wildcard search in Trie	🟡 Medium
4	Replace Words	Prefix replacement	🟡 Medium
5	Map Sum Pairs	Trie with values	🟡 Medium
6	Word Search II	Trie + DFS on grid	🔴 Hard
7	Maximum XOR of Two Numbers	Binary Trie	🔴 Hard
8	Stream of Characters	Trie + sliding window	🔴 Hard

🌍 Real-World Applications

Search autocomplete — Google and Bing suggest completions as you type
Spell checker — Word processors verify if a word exists in the dictionary
IP routing (LPM) — Routers use binary Tries for Longest Prefix Match
T9 predictive text — Mobile keyboard word prediction
DNA sequence matching — Biological sequence databases

Segment Tree: Tree structure specialized for range queries and updates ( $O(\log N)$ ).
Disjoint Set Union (DSU): Manages dynamic connectivity and equivalence relations ( $O(\alpha(N))$ ).
Two Pointers & Sliding Window: Efficient subarray and substring processing techniques ( $O(N)$ ).

🔗 References

🧠 Quick Quiz

Test Your Understanding

Answer these 3 questions to check what you have learned.

What is the main topic of this documentation page?

What should be identified before implementing trie?

How is understanding of trie best checked?

Track Your Progress

Done with this topic? Mark it as complete to track your progress.

Was this page helpful?

💬

Discuss this page

Have a question or spot something confusing in "Trie (Prefix Tree)"? Ask below. Backed by GitHub Discussions—maintainers receive system notifications directly.

Video Explanation​

🧠 Why Trie? — Comparison with Other Structures​

🌳 Trie Structure — Visual Diagram​

🔩 Node Structure​

➕ Operation 1: Insert​

Visual Dry-Run — Insert "app"​

Visual Dry-Run — Insert "apple" after "app"​

Code​

🔍 Operation 2: Search (Exact Word)​

Visual Dry-Run​

Code​

🔎 Operation 3: StartsWith (Prefix Search)​

Visual Dry-Run​

Code​

🗑️ Operation 4: Delete​

Visual Dry-Run​

Code​

✨ Bonus: AutoComplete Feature​

Visual Dry-Run​

Code​

⚡ Brute Force vs Trie​

📊 Complexity Summary​

❌ Common Mistakes​

🏋️ Practice Problems​

🌍 Real-World Applications​

🔗 Related Topics​

🔗 References​

Test Your Understanding

Was this page helpful?

Discuss this page

Video Explanation

🧠 Why Trie? — Comparison with Other Structures

🌳 Trie Structure — Visual Diagram

🔩 Node Structure

➕ Operation 1: Insert

Visual Dry-Run — Insert "app"

Visual Dry-Run — Insert "apple" after "app"

Code

🔍 Operation 2: Search (Exact Word)

Visual Dry-Run

Code

🔎 Operation 3: StartsWith (Prefix Search)

Visual Dry-Run

Code

🗑️ Operation 4: Delete

Visual Dry-Run

Code

✨ Bonus: AutoComplete Feature

Visual Dry-Run

Code

⚡ Brute Force vs Trie

📊 Complexity Summary

❌ Common Mistakes

🏋️ Practice Problems

🌍 Real-World Applications

🔗 Related Topics

🔗 References
