Disk Scheduling Algorithms
Disk Scheduling
Disk scheduling is the process used by an operating system to decide the order in which disk I/O requests are serviced. Since the movement of the disk's read/write head takes time, efficient scheduling algorithms aim to reduce seek time, improve performance, and increase disk throughput.
Video Explanation
1. First Come First Serve (FCFS)
FCFS services disk requests in the exact order they arrive.
1.1 How it Works
- Requests are placed in a queue.
- The disk head processes them one by one in arrival order.
1.2 Advantages
- Simple to implement.
- Fair, as requests are handled in arrival order.
1.3 Disadvantages
- Can result in large head movements.
- Poor overall seek time and performance.
1.4 Python Implementation
req = list(map(int, input("Enter request order: ").split()))
pos = int(input("Enter initial RW head position: "))
tot = int(input("Enter total number of tracks: "))
path = [pos]
seek = 0
cur = pos
for i in req:
seek += abs(i-cur)
cur = i
path.append(i)
print("\nFCFS RW head path: ", end="")
print(" -> ".join(map(str, path)))
print("Total seek time:", seek)
Example:
Input:
Enter request order: 83 92 1000 278 7803 25 78 30 786 2
Enter initial RW head position: 100
Enter total number of tracks: 8000
Output:
FCFS RW head path: 100 -> 83 -> 92 -> 1000 -> 278 -> 7803 -> 25 -> 78 -> 30 -> 786 -> 2
Total seek time: 18600
2. Shortest Seek Time First (SSTF)
SSTF selects the request closest to the current head position.
2.1 How it Works
- Calculate the distance between the current head position and all pending requests.
- Service the nearest request first.
- Repeat until all requests are completed.
2.2 Advantages
- Reduces total seek time.
- Better performance than FCFS.
2.3 Disadvantages
- Requests far from the current head position may experience starvation.
- Slightly more complex to implement.
2.4 Python Implementation
req = list(map(int, input("Enter request order: ").split()))
pos = int(input("Enter initial RW head position: "))
tot = int(input("Enter total number of tracks: "))
path = [pos]
seek = 0
cur = pos
while req:
x = min(req, key=lambda i: abs(i-cur))
seek += abs(x-cur)
cur = x
path.append(x)
req.remove(x)
print("\nSSTF RW head path: ", end="")
print(" -> ".join(map(str, path)))
print("Total seek time:", seek)
Example:
Input:
Enter request order: 83 92 1000 278 7803 25 78 30 786 2
Enter initial RW head position: 100
Enter total number of tracks: 8000
Output:
SSTF RW head path: 100 -> 92 -> 83 -> 78 -> 30 -> 25 -> 2 -> 278 -> 786 -> 1000 -> 7803
Total seek time: 7899
3. SCAN
SCAN moves the disk head in one direction, servicing all requests along the way, and then reverses direction.
3.1 How it Works
- The head moves toward one end of the disk.
- Services every request encountered.
- Upon reaching the end, it reverses and services requests in the opposite direction.
3.2 Advantages
- Provides good throughput.
- Reduces starvation compared to SSTF.
- More predictable waiting times.
3.3 Disadvantages
- Requests near the ends may wait longer.
- The head may travel to the disk boundary even when no requests exist there.
3.4 Python Implementation
req = list(map(int, input("Enter request order: ").split()))
pos = int(input("Enter initial RW head position: "))
tot = int(input("Enter total number of tracks: "))
d = input("Enter direction (l/r): ").strip().lower()
l = sorted([i for i in req if i < pos])
r = sorted([i for i in req if i >= pos])
path = [pos]
seek = 0
cur = pos
if d == "l":
for i in reversed(l):
seek += abs(i-cur)
cur = i
path.append(i)
seek += abs(cur-0)
cur = 0
path.append(0)
for i in r:
seek += abs(i-cur)
cur = i
path.append(i)
else:
for i in r:
seek += abs(i-cur)
cur = i
path.append(i)
seek += abs(cur-(tot-1))
cur = tot-1
path.append(tot-1)
for i in reversed(l):
seek += abs(i-cur)
cur = i
path.append(i)
print("\nSCAN RW head path: ", end="")
print(" -> ".join(map(str, path)))
print("Total seek time:", seek)
Example:
Input:
Enter request order: 83 92 1000 278 7803 25 78 30 786 2
Enter initial RW head position: 100
Enter total number of tracks: 8000
Enter direction (l/r): r
Output:
SCAN RW head path: 100 -> 278 -> 786 -> 1000 -> 7803 -> 7999 -> 92 -> 83 -> 78 -> 30 -> 25 -> 2
Total seek time: 15896
4. Circular SCAN (C-SCAN)
C-SCAN services requests in only one direction.
4.1 How it Works
- The head moves in a single direction, servicing requests.
- After reaching the end of the disk, it immediately returns to the beginning without servicing requests during the return trip.
- The process then repeats.
4.2 Advantages
- Provides more uniform waiting times.
- Fairer than SCAN for all disk locations.
4.3 Disadvantages
- Additional movement is required for the return jump.
- Slightly less efficient than SCAN in some cases.
4.4 Python Implementation
req = list(map(int, input("Enter request order: ").split()))
pos = int(input("Enter initial RW head position: "))
tot = int(input("Enter total number of tracks: "))
d = input("Enter direction (l/r): ").strip().lower()
l = sorted([i for i in req if i < pos])
r = sorted([i for i in req if i >= pos])
path = [pos]
seek = 0
cur = pos
if d == "l":
for i in reversed(l):
seek += abs(i-cur)
cur = i
path.append(i)
seek += abs(cur-0)
cur = 0
path.append(0)
seek += abs((tot-1)-cur)
cur = tot-1
path.append(tot-1)
for i in reversed(r):
seek += abs(i-cur)
cur = i
path.append(i)
else:
for i in r:
seek += abs(i-cur)
cur = i
path.append(i)
seek += abs((tot-1)-cur)
cur = tot-1
path.append(tot-1)
seek += abs(cur-0)
cur = 0
path.append(0)
for i in l:
seek += abs(i-cur)
cur = i
path.append(i)
print("\nCSCAN RW head path: ", end="")
print(" -> ".join(map(str, path)))
print("Total seek time:", seek)
Example:
Input:
Enter request order: 83 92 1000 278 7803 25 78 30 786 2
Enter initial RW head position: 100
Enter total number of tracks: 8000
Enter direction (l/r): r
Output:
CSCAN RW head path: 100 -> 278 -> 786 -> 1000 -> 7803 -> 7999 -> 0 -> 2 -> 25 -> 30 -> 78 -> 83 -> 92
Total seek time: 15990
5. LOOK
LOOK is an optimized version of SCAN.
5.1 How it Works
- The head moves in one direction and services requests.
- Instead of going all the way to the disk end, it reverses when the last request in that direction has been serviced.
5.2 Advantages
- Reduces unnecessary head movement.
- More efficient than SCAN.
5.3 Disadvantages
- Slightly more complex than FCFS and SSTF.
- Waiting times may still vary.
5.4 Python Implementation
req = list(map(int, input("Enter request order: ").split()))
pos = int(input("Enter initial RW head position: "))
tot = int(input("Enter total number of tracks: "))
d = input("Enter direction (l/r): ").strip().lower()
l = sorted([i for i in req if i < pos])
r = sorted([i for i in req if i >= pos])
path = [pos]
seek = 0
cur = pos
if d == "l":
for i in reversed(l):
seek += abs(i-cur)
cur = i
path.append(i)
for i in r:
seek += abs(i-cur)
cur = i
path.append(i)
else:
for i in r:
seek += abs(i-cur)
cur = i
path.append(i)
for i in reversed(l):
seek += abs(i-cur)
cur = i
path.append(i)
print("\nLOOK RW head path: ", end="")
print(" -> ".join(map(str, path)))
print("Total seek time:", seek)
Example:
Input:
Enter request order: 83 92 1000 278 7803 25 78 30 786 2
Enter initial RW head position: 100
Enter total number of tracks: 8000
Enter direction (l/r): r
Output:
LOOK RW head path: 100 -> 278 -> 786 -> 1000 -> 7803 -> 92 -> 83 -> 78 -> 30 -> 25 -> 2
Total seek time: 15504
6. Circular LOOK (C-LOOK)
C-LOOK is an optimized version of C-SCAN.
6.1 How it Works
- The head services requests in one direction only.
- After reaching the last request in that direction, it jumps directly to the first pending request at the opposite end.
- Servicing then continues in the same direction.
6.2 Advantages
- Eliminates unnecessary travel to disk boundaries.
- Provides uniform waiting times.
- More efficient than C-SCAN.
6.3 Disadvantages
- The jump between the last and first request still adds movement.
- Slightly more complex to implement.
6.4 Python Implementation
req = list(map(int, input("Enter request order: ").split()))
pos = int(input("Enter initial RW head position: "))
tot = int(input("Enter total number of tracks: "))
d = input("Enter direction (l/r): ").strip().lower()
l = sorted([i for i in req if i < pos])
r = sorted([i for i in req if i >= pos])
path = [pos]
seek = 0
cur = pos
if d == "l":
for i in reversed(l):
seek += abs(i-cur)
cur = i
path.append(i)
if r:
seek += abs(cur-r[-1])
cur = r[-1]
path.append(cur)
for i in reversed(r[:-1]):
seek += abs(i-cur)
cur = i
path.append(i)
else:
for i in r:
seek += abs(i-cur)
cur = i
path.append(i)
if l:
seek += abs(cur-l[0])
cur = l[0]
path.append(cur)
for i in l[1:]:
seek += abs(i-cur)
cur = i
path.append(i)
print("\nCLOOK RW head path: ", end="")
print(" -> ".join(map(str, path)))
print("Total seek time:", seek)
Example:
Input:
Enter request order: 83 92 1000 278 7803 25 78 30 786 2
Enter initial RW head position: 100
Enter total number of tracks: 8000
Enter direction (l/r): r
Output:
CLOOK RW head path: 100 -> 278 -> 786 -> 1000 -> 7803 -> 2 -> 25 -> 30 -> 78 -> 83 -> 92
Total seek time: 15594
7. Summary
| Algorithm | Main Idea | Starvation | Efficiency |
|---|---|---|---|
| FCFS | Service requests in arrival order | No | Low |
| SSTF | Service nearest request first | Possible | High |
| SCAN | Move back and forth like an elevator | Rare | High |
| C-SCAN | Service in one direction only | No | High |
| LOOK | SCAN without going to disk ends | Rare | Very High |
| C-LOOK | C-SCAN without going to disk ends | No | Very High |
Among these algorithms, LOOK and C-LOOK are generally preferred because they reduce unnecessary head movement while maintaining good performance and fairness.
