Gray Code Generation Using Recursion

Ayesha
EditReport

Gray Code Generation Via RecursionтАЛ

Problem Statement:

  • The objective is to generate the Gray code sequence for a given integer nnn, where nnn represents the number of bits. Gray codes are binary sequences where each consecutive code differs from the previous one by exactly one bit. This property is particularly useful in various applications such as digital communication, error correction, and minimizing transitions in hardware.

Video Explanation

Input:

  • An integer n (1 тЙд n тЙд 16) representing the number of bits for which the Gray code needs to be generated.

Output:

  • A list of 2^n Gray codes, each represented as a binary string of length n.

Constraints:

  • The output should follow the Gray code sequence rules.
  • The implementation should ensure efficient computation, especially for larger values of n.

C++ implementation :

Output :

Enter the number of bits: 4 Gray Code for 4 bits: 0000 0001 0011 0010 0110 0111 0101 0100 1100 1101 1111 1110 1010 1011 1001 1000

Code :

 #include <iostream>
#include <vector>
#include <string>

std::vector<std::string> generateGrayCode(int n) {
    if (n == 0) {
        return {""}; // Base case: Gray code for 0 bits
    }

    // Recursive call to generate Gray code for n-1 bits
    std::vector<std::string> previousGrayCode = generateGrayCode(n - 1);
    std::vector<std::string> grayCode;

    // Prepend '0' to the first half
    for (const std::string &code : previousGrayCode) {
        grayCode.push_back("0" + code);
    }

    // Prepend '1' to the reversed second half
    for (int i = previousGrayCode.size() - 1; i >= 0; --i) {
        grayCode.push_back("1" + previousGrayCode[i]);
    }

    return grayCode;
}

int main() {
    int n;
    std::cout << "Enter the number of bits to be entered : ";
    std::cin >> n;

    std::vector<std::string> grayCode = generateGrayCode(n);

    std::cout << "Gray Code for " << n << " bits:\n";
    for (const std::string &code : grayCode) {
        std::cout << code << "\n";
    }

    return 0;
}
