Sum of Subarray Ranges

Description:​

You are given an integer array nums. The range of a subarray of nums is the difference between the largest and smallest element in the subarray.

Return the sum of all subarray ranges of nums.

A subarray is a contiguous non-empty sequence of elements within an array.

Example 1: Input: nums = [1,2,3] Output: 4 Explanation: The 6 subarrays of nums are the following: [1], range = largest - smallest = 1 - 1 = 0 [2], range = 2 - 2 = 0 [3], range = 3 - 3 = 0 [1,2], range = 2 - 1 = 1 [2,3], range = 3 - 2 = 1 [1,2,3], range = 3 - 1 = 2 So the sum of all ranges is 0 + 0 + 0 + 1 + 1 + 2 = 4.

Example 2: Input: nums = [1,3,3] Output: 4 Explanation: The 6 subarrays of nums are the following: [1], range = largest - smallest = 1 - 1 = 0 [3], range = 3 - 3 = 0 [3], range = 3 - 3 = 0 [1,3], range = 3 - 1 = 2 [3,3], range = 3 - 3 = 0 [1,3,3], range = 3 - 1 = 2 So the sum of all ranges is 0 + 0 + 0 + 2 + 0 + 2 = 4.

Video Explanation​

Watch

Approaches:​

1. Monotonic Stack​

The problem asks for the sum of all subarray ranges. We can optimize this using a Monotonic Stack by realizing that: $\sum \text{(Range)} = \sum \text{(Maximum of Subarray)} - \sum \text{(Minimum of Subarray)}$

To find these sums efficiently, we need to determine how many subarrays a specific element acts as the maximum, and how many it acts as the minimum.

1. For the Minimums: We use a monotonically increasing stack to find the Previous Smaller Element and Next Smaller Element.
2. For the Maximums: We use a monotonically decreasing stack to find the Previous Greater Element and Next Greater Element.
3. Handling Duplicates: To avoid double-counting subarrays when there are duplicate numbers, we use a strict inequality < on one side and a non-strict inequality <= on the other.

• Time Complexity: $O(N)$ because we iterate through the array a constant number of times. Each element is pushed and popped from the stack exactly once.
• Space Complexity: $O(N)$ to store elements in the stack. In the worst-case scenario, the stack will store $N$ elements.

Monotonic Stack Solutions:​

Solutions​

#include <vector>

using namespace std;

class Solution {
public:
    long long subArrayRanges(vector<int>& nums) {
        int n = nums.size();
        long long res = 0;
        vector<int> st;

        // Sum of Minimums
        for (int i = 0; i <= n; ++i) {
            while (!st.empty() && (i == n || nums[st.back()] > nums[i])) {
                int j = st.back();
                st.pop_back();
                int left = j - (st.empty() ? -1 : st.back());
                int right = i - j;
                res -= 1LL * nums[j] * left * right;
            }
            st.push_back(i);
        }

        st.clear();

        // Sum of Maximums
        for (int i = 0; i <= n; ++i) {
            while (!st.empty() && (i == n || nums[st.back()] < nums[i])) {
                int j = st.back();
                st.pop_back();
                int left = j - (st.empty() ? -1 : st.back());
                int right = i - j;
                res += 1LL * nums[j] * left * right;
            }
            st.push_back(i);
        }

        return res;
    }
};

import java.util.ArrayDeque;
import java.util.Deque;

class Solution {
    public long subArrayRanges(int[] nums) {
        int n = nums.length;
        long res = 0;
        Deque<Integer> st = new ArrayDeque<>();

        // Sum of Minimums
        for (int i = 0; i <= n; i++) {
            while (!st.isEmpty() && (i == n || nums[st.peek()] > nums[i])) {
                int j = st.pop();
                int left = j - (st.isEmpty() ? -1 : st.peek());
                int right = i - j;
                res -= (long) nums[j] * left * right;
            }
            st.push(i);
        }

        st.clear();

        // Sum of Maximums
        for (int i = 0; i <= n; i++) {
            while (!st.isEmpty() && (i == n || nums[st.peek()] < nums[i])) {
                int j = st.pop();
                int left = j - (st.isEmpty() ? -1 : st.peek());
                int right = i - j;
                res += (long) nums[j] * left * right;
            }
            st.push(i);
        }

        return res;
    }
}

class Solution:
    def subArrayRanges(self, nums: list[int]) -> int:
        n = len(nums)
        res = 0

        # Sum of Minimums
        stack = []
        for i in range(n + 1):
            while stack and (i == n or nums[stack[-1]] > nums[i]):
                j = stack.pop()
                left = j - stack[-1] if stack else j + 1
                right = i - j
                res -= nums[j] * left * right
            stack.append(i)

        # Sum of Maximums
        stack = []
        for i in range(n + 1):
            while stack and (i == n or nums[stack[-1]] < nums[i]):
                j = stack.pop()
                left = j - stack[-1] if stack else j + 1
                right = i - j
                res += nums[j] * left * right
            stack.append(i)

        return res

/**
 * @param {number[]} nums
 * @return {number}
 */
var subArrayRanges = function(nums) {
    const n = nums.length;
    let res = 0;
    let st = [];

    // Sum of Minimums
    for (let i = 0; i <= n; i++) {
        while (st.length > 0 && (i === n || nums[st[st.length - 1]] > nums[i])) {
            let j = st.pop();
            let left = j - (st.length === 0 ? -1 : st[st.length - 1]);
            let right = i - j;
            res -= nums[j] * left * right;
        }
        st.push(i);
    }

    st = [];

    // Sum of Maximums
    for (let i = 0; i <= n; i++) {
        while (st.length > 0 && (i === n || nums[st[st.length - 1]] < nums[i])) {
            let j = st.pop();
            let left = j - (st.length === 0 ? -1 : st[st.length - 1]);
            let right = i - j;
            res += nums[j] * left * right;
        }
        st.push(i);
    }

    return res;
};
